| C. S and Alloy Pipe |
| |
| |
 Material (According to ASTM Standard) |
|
| Specification |
Commentary |
Grade |
Types |
Material |
| A 106 |
Seamless C-Steel Pipe
for High Temperature Service |
A & B |
Seamless |
Carbon Steel |
| API 5L |
Line Pipe |
A, B, X42,
X46, X52, X60,
X65, X70, X80 |
Seamless & Welded |
Carbon Steel |
| A 53 |
Welded and Seamless Steel Pipe |
A & B |
Seamless & Welded |
Carbon Steel |
| A 333 |
Seamless and Welded Pipe for Low Temperature Service |
1 |
Seamless & Welded |
Carbon Steel |
| 6 |
Seamless & Welded |
Carbon Steel |
| 3 |
Seamless & Welded |
3 ¨ö% Ni |
| 8 |
Seamless & Welded |
9% Ni |
| A 335 |
Seamless Ferritic Alloy Steel Pipe for
High Temperature Service |
P1 |
Seamless |
Carbon-Mo |
| P12 |
Seamless |
1 Cr - ¨ö Mo |
| P11 |
Seamless |
1 ¨ùCr - ¨ö Mo |
| P22 |
Seamless |
2 ¨ù Cr - 1 Mo |
| P5 |
Seamless |
5 Cr - ¨ö Mo |
| P9 |
Seamless |
9 Cr - 1 Mo |
| A 691 |
Electric Fusion Welded C and Alloy
Steel Pipe for High Temperature |
¡¡ |
Welded |
¡¡ |
|
| |
| |
 |
| |
 |
1 : A 106 Gr. B
2 : API 5L Line Pipe
3 : A 53 Gr. A
4 : A 335 P11
5 : A 333 Gr. 6 |
| |
| |
| |
|
| |
|
| |
|
|
